HP Latex R530 Printer

HP Latex R530 — Compact Hybrid Printer for Rigid & Flexible Media

Vivid Colour. Versatile Applications. Sustainable Performance.

Deliver sharp, vibrant output across rigid and roll-fed media with the HP Latex R530. This compact hybrid printer combines rigid-substrate capability with flexible printing in a single, space-efficient unit.

Quality & Versatility:

• Print at up to 1200 × 600 dpi, supporting smooth gradients, solids, and detailed imagery.
• Use the HP High Control Belt System for stable, precise rigid printing.
• Supports white ink with automatic recirculation and printhead cleaning to maintain consistency in multilayer effects.

Efficiency:

• Operates on single-phase power, offering simpler installation requirements.
• Features intuitive touchscreen controls and fast transitions between rigid and flexible media.
• Handles rolls from 18″ to 64″ in width and rigid media up to 2″ thick.

Performance:

• In draft mode, it prints at ~31 m²/h (~334 ft²/h).
• In higher-quality modes or while printing white layers, speeds reduce accordingly.
• Supports heavy materials: rigid media up to ~150 lb and roll weight up to ~121 lb.

Sustainability:

• Uses water-based HP Latex Inks, enabling low-odor prints suitable for indoor environments.
• Designed to support circular workflows with returnable maintenance cartridges and recyclable substrate handling.
